GF-T81 타이어 체인저( 반자동)

The Guorange T81 is an industrial-grade semi-automatic tire changer engineered for high-throughput automotive repair shops, tire service bays, and commercial fleet garages. Powered by a high-torque 2.0HP (1.5kW) pure copper motor and reinforced alloy steel clamping jaws, the T81 handles rim diameters up to 24 inches and wheel widths up to 15 신장 (380mm) with continuous operational stability. Featuring an enclosed protective chassis, a modular pull-type pedal system, and multi-point rim protection hardware, this unit combines mechanical durability with low maintenance overhead for professional tire technicians.

주요 특징 :

Carburized Alloy Steel Jaws: Heavy-duty clamping jaws treated with a 0.8–1.1mm deep carburization and full quenching process, delivering high surface hardness alongside internal tensile ductility. Includes clip-on jaw covers to prevent alloy rim marring.
Polished Stainless Demount Head: Solution-treated stainless steel mounting head designed with an ergonomic contour and fitted with replaceable plastic rim protectors for safe, metal-on-metal-free mounting and demounting.
High-Torque Pure Copper Motor: Powered by a 2.0HP (1.5kW) motor with pure copper windings, ensuring rapid heat dissipation, high rotation torque (6.8 RPM), and extended duty cycles under continuous shop loads.
Modular Pull-Type Pedal Assembly: Front-accessible pull-type valve block architecture allows technicians to perform maintenance or valve replacements quickly without disassembling the entire chassis.
Pneumatic Protection & 비드 브레이킹: High-output pneumatic bead breaker equipped with a durable spade protector, integrated foot-pedal-controlled tire inflation gauge, and an industrial-grade air filter-regulator-lubricator unit to prolong pneumatic valve life.
Enclosed Chassis Construction: Fully enclosed high-tensile steel housing keeps shop dust, moisture, and debris away from internal mechanical drives and electrical connections.

Configurable Options (B2B Customization)

We configure power units and structural details prior to production to match regional electrical standards and OEM distribution requirements:
- Electrical Configurations: Standard North American 120다섯 / 1PH / 2.0HP setup, or pre-configured 220다섯 / 380다섯 (50/60Hz, Single or Three-Phase) for global markets.
- 상표 & Finish Customization: Custom industrial powder coatings, tailored nameplates, private-label packaging, and optional auxiliary accessories (Low MOQ available).

  B2B Commercial & Support Terms
  - Commercial Warranty: Full manufacturer warranty covering the pure copper motor, structural turntable, and pneumatic assemblies, supported by expedited replacement parts authorization.
  - Global Freight & Mixed Loading: Export-grade crating optimized for container utilization; fully supports mixed-container logistics with wheel balancers and car lifts.
  - Factory Technical Channel: Direct access to factory engineers for remote diagnostics, pneumatic system troubleshooting, and parts support.

명세서

Equipment Model	Guorange T81
Operation Type	Semi-Automatic (Swing-Arm Style)
Outside Clamping Range	12" – 20" (305 – 508 mm)
Inside Clamping Range	14" – 24" (356 – 610 mm)
최대 휠 직경	41" (1,040 mm)
Max Wheel Width	15" (380 mm)
Motor Power	2.0 HP (1.5 kW) Pure Copper Winding
Turntable Rotation Speed	6.8 r/min
Operating Air Pressure	0.8 – 1.0 MPa (116 – 145 psi)
Power Supply	120다섯 / 1PH (Configurable 220V / 380다섯)
순중량 (Machine)	186 KG
Compliance & Standards	Full CE & EAC Certified for Global Export

자주 묻는 질문

Q1: What are the durability advantages of the carburized jaws and stainless demount head?

The clamping jaws undergo a dual thermal treatment (0.8–1.1mm depth carburization plus full quenching) that creates an extremely hard outer surface to resist tooth wear while maintaining internal core toughness against high-torque fracture. The solution-treated stainless steel tool head resists corrosion and mechanical deformation, while polymer protective inserts ensure zero wheel contact scratches.

Q2: Can the T81 power unit be customized for regions outside North America?

예. While the standard configuration features a high-output 120V/1PH/2.0HP motor optimized for the North American grid, we build and certify power configurations for 220V/240V/380V (50Hz or 60Hz) grids prior to shipment.

Q3: How does the pull-type pedal design reduce shop downtime?

Standard tire changer valve systems often require extensive body disassembly for simple pneumatic seal changes. The T81 utilizes an integrated pull-type drawer mechanism that allows the entire pedal and valve block to slide out directly from the front, cutting routine servicing and valve maintenance time by over 50%.
